CodeMark Certified and suitable for timber or steel framed buildings.
Key Benefits
Compatible with all building wraps
Simple 4-step installation, save time and reduces costs
1 mm thick adhesive layer
Reliable and dependable weather tightness
Low-temperature adhesion. Can be applied as low as 5°C
A Masons Corner Guard is easy to install and increases protection to framing
Installation
Windows/Door/Timber and Steel Frame Flashings Masons Hydro Flashing Tape and Masons Corner Guard must be installed in accordance with these instructions.
Ensure the Hydro Tape completely covers the joinery opening.
To ensure maximum adhesion of the tape, make sure the substrate surface is clean, dry and free from any dust or other contaminants. Flaps are folded into the opening and secured.
The building wrap is installed as shown on the exterior face of the frame. At window and door openings it is cut at a 45˚ angle away from each corner, and then the flaps are folded into the opening and secured.
Hydro Flashing Tape must not be stretched. When joining 2 sections of tape, overlap by 100mm or more.
NOTE: 150mm Wide tape is used for 100mm wide window or door framing. 200mm Wide tape is used for 140mm–150mm wide revels.
WARNING: Don’t apply any solvent-based glues or adhesives/sealants to the tape as it will react with the bitumen.
Technical
information
Browse downloadable product files.
75mm x 25m
150mm x 25m
200mm x 25m
50 pack
10 pack
